SATCOM Technology of Elaborated Luneburg Lens Antenna
We invented a state-of-the-art antenna system STELLA® , a satellite communication antenna product in Low Earth Orbit (LEO-Satcom) with a device as small as a golf ball size for the Q-band frequency (33 – 50GHz). Our X-band antenna device, 8 – 12GHz, with operation extension going beyond the Ku-band (up to 20GHz) is less than a basket ball size. The patent pending STELLA® antenna device is being developed for the X, Ku, Ka, Q, V and W bands. Our antenna system is easily integrable to existing Satcom technologies such as ground terminals and other communication systems. The small footprint of the antenna device supports integration to equipment systems with limited payload such as Cubesats and mobile gateways.
US Air Tech dba USAT products line will include SATCOM ground station, satellite modules and in-orbit crosslink devices for satellite modules operating in optical frequencies (laser light radiation). Laser communications (optical frequencies), downlink and uplink, are part of our R&D (Research and Development) endeavors.
The unique features of the patent pending STELLA® antenna system include an extremely wide scanning angle capability and a blanket coverage of the sky or the Earth with no dead zone in the electromagnetics wave illumination pattern. STELLA® has 360 degree in azimuth and 180 degree in elevation scanning capability, a simultaneous connection and tracking of several LEO (Low Earth Orbit) satellites with zero dead zone and zero downtime during tracking, a customizable downlink radiation light beam pattern shape to cover specific geographical Earth area of interest, an advanced control of the radiated electromagnetic beam characteristics (polarization, beamwidth, beam pattern,…) and a resourcefully available transmission power as needed. STELLA’s® reduced footprint is a game changer for the miniaturization of Satcom gateways, reduction of square-footage requirement for teleport ground infrastructure and minimization of teleport operational power. STELLA® antenna system is ruggedized for austere operational environment. The antenna system has no moving parts (such as parabolic reflector antennas) and has no complex electronics as found in phased-array antenna system. These later features enable STELLA® a higher MTBF (Mean Time Between Failure) - 50% more than a phased-array antenna system - and support a very low-cost maintenance rate in comparison to existing Satcom antenna technologies of parabolic reflectors, flat panels and phased-array.
USAT’s contribution to the advancement of SATCOM® technology will be undeniable and impactful. STELLA’s® 3D printed lens antenna is a low-cost production device. It will modestly promote the proliferation of Satcom internet and 5G mobile cellular phone. The direct addressable market of STELLA® are the Low Earth Orbit communication applications of SATCOM including IoT (Internet-of-Things). Voice and data applications (including BigData) are directly served. Services will be enhanced with the following important societal areas: Tele-Health including the emerging Remote Surgery (medical surgery performed on patients half the Globe distance away), Remote Education, Tele-Work, Tele-Conferencing. Underserved remote areas (areas with difficult communication cables access) and disadvantaged communities will benefit from the proliferation of the LEO SATCOM enabled by the low-cost production of STELLA® .
This modest contribution was made possible by the Government funding that USAT was honored to receive. We are grateful to the Government endorsement to our effort, the National Science Foundation (NSF) award and support provided to USAT and the vibrant support from our local community.
It is our commitment to pursue our dedication to the company core motto of:
"SATCOM GLOBAL CONNECTIVITY – We bring people together ".
Our R&D (Research and Development) targets products that extend to ground station, cubesat, satellite modules, and handheld SATCOM devices.
Our flagship product STELLA® antenna system has technical capabilities that include 5G mobile phone applications. We anticipate a high data bandwidth in 1000s of Gb (terabyte) enabled by a unique, patent pending, design and data speed rate beyond current ethernet capabilities of 10Gbps. The data rate speed will be limited only by communication architectures and algorithms.
USAT 5G antenna design will provide a connectivity to Satcom and urban mobile phone/internet in compliance with the 5G technical requirements. The connectivity will result in higher speed in 1000s of Gb/s (Tb/s) and higher bandwidth in Tb.
USAT’s technology will deliver connectivity performance in 1000s of Gb/s (Tb/s) and higher bandwidth in Tb. This antenna technology has not been commercially demonstrated yet and not currently available on the market. USAT is working to bring this technology to the communication market.
USAT’s dedicated team counts talented scientists, engineers, professionals from various expertise to deliver unique solution in Satcom and 5G mobile phone applications. It is all about people and how to better serve human societies and contribute modestly to human conditions betterment and togetherness.
USAT is developing a synergetic communication products family in an ecosystem that is open to integration with existing technologies and hardware. These products family include full Satcom ground terminal, satellite modules (CubeSat and larger), handheld Satcom devices, 5G cellphone tower and ultra sensitive receivers that will feature advanced LNBs (Low Noise Block downconverters).
Read More
"Do not limit your challenges, Challenge your limits"!
Our researchers constantly strive to be at the technology frontiers, in a permanent challenge of current technology limits. What is next, what is the future and what is beyond the current state-of-the-art technology are questions that continually float in our laboratories.
About the National Science Foundation's Small Business Programs: America’s Seed Fund powered by NSF awards $200 million annually to startups and small businesses, transforming scientific discovery into products and services with commercial and societal impact. Startups working across almost all areas of science and technology can receive up to $2 million to support research and development (R&D), helping de-risk technology for commercial success. America’s Seed Fund is congressionally mandated through the Small Business Innovation Research (SBIR) program. The NSF is an independent federal agency with a budget of about $8.5 billion that supports fundamental research and education across all fields of science and engineering.
USAT won the Optics Valley 2021 prize of Best Arizona Technology of IdeaFunding 2021 competition
The University of Arizona Center for Innovation (UACI) is a startup incubator network with locations across the Southern Arizona region. The UACI offers leaders of science and technology startups the expertise, connections to the University of Arizona, incubation programs and office and lab space needed to turn ideas and inventions into strong, scalable and sustainable businesses that ultimately provide high-paying jobs and fuel Southern Arizona’s economy.
The NSF Innovation Corps ( National Science Foundation’s Innovation Corps I-Corps™ ) program uses experiential education to help researchers gain valuable insight into entrepreneurship, starting a business or industry requirements and challenges.
I-Corps enables the transformation of invention to impact. The curriculum integrates scientific inquiry and industrial discovery in an inclusive, data-driven culture driven by rigor, relevance, and evidence. Through I-Corps training, researchers can reduce the time to translate a promising idea from the laboratory to the marketplace.
NSF is developing and nurturing a national innovation network to guide scientific research toward the development of solutions to benefit society.
